TKC-BSN Open Loop Hall Effect Current Sensor

TKC-BSN Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm.

The TKC-BSN series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

Technology :
Open loop Hall effect
Max. Nominal Value :
±600A
Max. Measuring Range :
±900A
Output Signal :
±4V
Supply Voltage :
±15V ±5%
Accuracy :
1%
Op. Temperature :
-40 °C / 105 °C
Mounting :
Aperture 20.5x10.5mm
Weight :
60g
MOQ :
96

Inquiry now

RELATED PRODUCTS

TKC-BS Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. TKC-BS series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BR Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. TKC-BR series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, provides wires. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BAS Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BAS series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BAR Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BAR series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, provides wires, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BXS Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BXS series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BXR1 Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BXR1 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSN Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BSN series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BS1 Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BS1 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BS2 Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BS2 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSW Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BSW series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSW1 Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BSW1 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BP1 Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BP1 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BP2 Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BP2 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BS2A4 Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BS2A4 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BS2A Open Loop Hall Effect Current Sensor

Input ±50 - ±600A, Output ±5V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-BS2A series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-NA1540 Hall Effect Current Sensor

Input ±40 - ±200A, Output ±40mV, Power Supply ±15V, Aperture 20x15mm. The TKC-NA1540 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 40A and 200A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-N Open Loop Mode Hall Effect Current Sensor

Input ±100 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-N series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-NR Open Loop Hall Effect Current Sensor

Input ±100 - ±600A, Output ±4V, Power Supply ±15V, Aperture 20.5x10.5mm. The TKC-NR series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-F Open Loop Hall Effect Current Sensor

Input ±100 - ±2000A, Output ±4V, Power Supply ±15V, Aperture 41x12mm. The TKC-F series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto 3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-FR Open Loop Hall Effect Current Sensor

Input ±100 - ±2000A, Output ±4V, Power Supply ±15V, Aperture 41x12mm. The TKC-FR series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto 3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-F51 Open Loop Hall Effect Current Sensor

Input ±100 - ±2000A, Output ±1V, Power Supply ±5V, Aperture 20.5x10.5mm. The TKC-F51 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-FA Open Loop Hall Effect Current Sensor

Input ±100 - ±2000A, Output ±4V, Power Supply ±15V, Aperture 40x20mm. The TKC-FA series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto 3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-HAT Open Loop Hall Effect Current Sensor

Input ±200 - ±1500A, Output ±4V, Power Supply ±15V, Aperture 40.5x30.5mm. The TKC-HAT series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 200A and 1500A, meansure range upto 3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-HAX Open Loop Hall Effect Current Sensor

Input ±500 - ±5000A, Output ±4V, Power Supply ±15V, Aperture 64x21mm. The TKC-HAX series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 500A and 5000A, meansure range upto 10000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-HAX128 Open Loop Hall Effect Current Sensor

Input ±500 - ±2500A, Output ±12mA, Power Supply ±12V, Aperture 64x21mm. The TKC-HAX128 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 500A and 2500A, meansure range upto 3750A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-HAX248 Open Loop Hall Effect Current Sensor

Input ±500 - ±2500A, Output ±12±8, Power Supply ±24V, Aperture 64x21mm. The TKC-HAX248 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 500A and 2500A, meansure range upto 3750A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-HB Open Loop Hall Effect Current Sensor

Input ±1000 - ±20000A, Output ±4V, Power Supply ±15V, Aperture 140x50mm. The TKC-HB series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 1000A and 20000A, meansure range upto 30000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-E Open Loop Hall Effect Current Sensor

Input ±50 - ±500A, Output ±4V, Power Supply ±15V, Aperture 20.5mm. The TKC-E series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto 1000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EA Series Open Loop Mode Hall Effect Current Sensor

Input ±200 - ±2000A, Output ±4V, Power Supply ±15V, Aperture 40.5mm. The TKC-EA series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 200A and 2000A, meansure range upto 3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-LB Open Loop Hall Effect Current Sensor

Input ±50 - ±300A, Output ±4V, Power Supply ±12-±15V, Aperture 16mm. The TKC- LB series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 300A, meansure range upto 450A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-PZ Open Loop Hall Effect Current Sensor

Input ±50 - ±800A, Output ±4V, Power Supply ±15V, Aperture 20x10mm. The TKC-PZ series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 800A, meansure range upto 1000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-PT3 Three-phase Hall Effect Current Sensor

Input ±50 - ±200A, Output ±4V, Power Supply ±15V, Aperture 12x10mm. The TKC-PT3 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 200A, meansure range upto 600A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-TG3 Three-phase Open Loop Hall Effect Current Sensor

Input ±50 - ±200A, Output ±4V, Power Supply ±15V, Aperture 12x9.5mm. The TKC-TG3 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 200A, meansure range upto 600A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-GT Series Open Loop Mode Hall Effect Current Sensor

Input ±500 - ±5000A, Output ±4V, Power Supply ±15V, Aperture 104x34mm. The TKC-GT series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 500A and 5000A, meansure range upto 10000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-GT1540 Hall Effect Current Sensor

Input 750A, Output ±40mV, Power Supply ±15V, Aperture 104x34mm. The TKC-GT1540 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 750A, meansure range upto 4800A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-GTS1540 Hall Effect Current Sensor

Input ±250 - ±470A, Output ±40mV, Power Supply ±15V, Aperture 40x20mm. The TKC-GTS1540 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 250A and 470A, meansure range upto 2700A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSF5 Open Loop Hall Effect Current Sensor

The TKC-BSF5 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSF565 Open Loop Hall Effect Current Sensor

The TKC-BSF565 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSF52 Open Loop Hall Effect Current Sensor

The TKC-BSF52 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 660A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRF5 Open Loop Hall Effect Current Sensor

The TKC-BRF5 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRF565 Open Loop Hall Effect Current Sensor

TKC-BRF52 Open Loop Hall Effect Current Sensor

TKC-BSFR5 Open Loop Hall Effect Current Sensor

TKC-BSFR565 Open Loop Hall Effect Current Sensor

The TKC-BSFR565 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSFR52 Open Loop Hall Effect Current Sensor

The TKC-BSFR52 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 660A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRFR5 Open Loop Hall Effect Current Sensor

The TKC-BRFR5 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRFR565 Open Loop Hall Effect Current Sensor

The TKC-BRFR565 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRFR52 Open Loop Hall Effect Current Sensor

TKC-BSF12 Open Loop Hall Effect Current Sensor

The TKC-BSF12 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSF122 Open Loop Hall Effect Current Sensor

The TKC-BSF122 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 660A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRF12S Open Loop Hall Effect Current Sensor

The TKC-BRF12S series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRF122 Open Loop Hall Effect Current Sensor

The TKC-BRF122 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 660A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSFR12 Series Open Loop Mode Hall Effect Current Sensor

The TKC-BSFR12 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BSFR122 Open Loop Hall Effect Current Sensor

The TKC-BSFR122 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 660A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRFR12 Open Loop Hall Effect Current Sensor

The TKC-BRFR12 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 900A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-BRFR122 Open Loop Hall Effect Current Sensor

The TKC-BRFR122 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 600A, meansure range upto 660A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC- EKA Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKA series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto 1000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKA51 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKA51 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto 1000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKA52 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKA52 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto 550A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKA565 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKA565 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto 1000A, with wire, no potentiometer. It has 5% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKA242 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKA242 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto 550A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKA420/12 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKA420/12 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto -125～+1000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKA420/24 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKA420/24 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto -125～+1000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKAA128 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKAA128 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 20A and 500A, meansure range upto 600A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKAA248 Open Loop Mode Dismountable Hall Effect Current Sensor

The TKC-EKAA248 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 20A and 500A, meansure range upto 600A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKAA1210 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKAA1210 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto -500-+1000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKAA2410 Open Loop Dismountable Hall Effect Current Sensor

The TKC-EKAA2410 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 50A and 500A, meansure range upto-500-+1000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKB Open Loop Hall Effect Current Sensor

The TKC-EKB series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 200A and 2000A, meansure range upto 4000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKB51 Open Loop Dismountable Hall Effect Current Transmitter

The TKC-EKB51 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto 4000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKB52 Open Loop Dismountable Hall Effect Current Transmitter

The TKC-EKB52 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto 2200A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKB420/12 Open Loop Dismountable Hall Effect Current Transmitter

The TKC-EKB420/12 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto-500-+3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKB420/24 Open Loop Dismountable Hall Effect Current Transmitter

The TKC-EKB420/24 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto -500-+3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKB128 Open Loop Dismountable Hall Effect Current Transmitter

The TKC-EKB128 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto 3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-EKB248 Series Open Loop Mode Dismountable Hall Effect Current Transmitter

The TKC-EKB248 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 100A and 2000A, meansure range upto 3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-K Open Loop Dismountable Hall Effect Current Sensor

The TKC-K series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 400A and 3000A, meansure range upto 4500A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-H Open Loop Dismountable Hall Effect Current Sensor

The TKC-H series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 600A and 3000A, meansure range upto 4500A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-KA420/12 Open Loop Dismountable Hall Effect Current Sensor

The TKC-KA420/12 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 400A and 3200A, meansure range upto -500～+3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-KA420/24 Open Loop Dismountable Hall Effect Current Sensor

The TKC-KA420/24 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 400A and 2000A, meansure range upto -500～+3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-KAA128 Open Loop Dismountable Hall Effect Current Sensor

The TKC-KAA128 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 80A and 2000A, meansure range upto -2000-+300A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

TKC-KAA248 Open Loop Dismountable Hall Effect Current Sensor

The TKC-KAA248 series current sensor is an open loop device provides accurate electronic measurement of DC, AC or pulsed currents. This series current sensor has rated current input between 80A and 2000A, meansure range upto -2000-+3000A, with wire, no potentiometer. It has 1% accuracy, very small size, very reliable. Available for appearance customization.

More products uploading

Add: NO.80 Feitian Avenue, Lukou Street, Jiangning District, Nanjing City

Mob: +8619974076476

Email : sale2@token-sensor.com

Tel : +8602584912339

Hot Tags

Please read on, stay posted, subscribe, and we welcome you to tell us what you think.

submit

leave a message

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.

home

products

Type Parameter	TKC50 BSN	TKC75 BSN	TKC100 BSN	TKC200 BSN	TKC300 BSN	TKC400 BSN	TKC500 BSN	TKC600 BSN	Unit
Rated input (Ipn)	±50	±75	±100	±200	±300	±400	±500	±600	A
Measure range(Ip)	±150	±225	±300	±600	±900	±900	±900	±900	A
Rated output	@Ip=±Ipn ±4±1%								V
Supply voltage	±15 ±5%								V
Power consumption	+25,-15								mA
Offset voltage	±25								mV
Magnetic offset	±30	±25 @Ip=±Ipn-0							mV
Offset drift	≤±1.0	≤±0.75							mV/℃
Output drift	≤±1.0	≤±0.75							mV/℃
Linearity	@Ip=0-±Ipn ≤1								%FS
Response time	@50A/μS, 10%-90% ≤5								μS
Bandwidth	@-3dB DC±25								KHz
Galvanic isolation	@ 50HZ，AC，1min 2.5								KV
